Key Features
- Xilinx Zynq XC7Z015 SoC
- 2x SFP optical interfaces — up to 6.25Gbps
- HDMI output with ADI dedicated HDMI chip, 1080p@60Hz
- PCIe 2.0 x1 (5Gbps)
- Dual Gigabit Ethernet (1x PS, 1x PL)
- 4x USB 2.0 Host ports
- SD card for system boot
- 2x 40-pin expansion headers (compatible with MicroPhase ADDA, camera, and LCD modules)
- DC jack or PCIe motherboard power, 12V/2A with 2A fuse
Specifications
| Item | Specification |
|---|---|
| SoC | Xilinx Zynq XC7Z015 |
| SFP | 2x, up to 6.25Gbps |
| HDMI Output | 1x, ADI chip, 1080p@60Hz |
| PCIe 2.0 | x1, 5Gbps |
| Ethernet | 2x GbE (1x PS, 1x PL) |
| USB 2.0 Host | 4x |
| SD Card | 1x |
| USB-UART | 1x |
| JTAG | 10-pin 2.54mm standard |
| LEDs | 1 power + 4 user (1 PS, 3 PL) |
| Buttons | 1 reset + 2 user (1 PS, 1 PL) |
| Expansion | 2x 40-pin headers (ADDA, camera, LCD modules) |
| Input Voltage | 12V/2A |
| Fuse | 2A |
| Power | DC jack / PCIe motherboard |
Pricing available on request — use the “Request a Quote” button for B2B inquiries.
