Key Features
- Xilinx Zynq-7020 SoC (ARM Cortex-A9 + FPGA fabric)
- 4Gbit DDR3 SDRAM at 1066Mbps
- Onboard USB-JTAG — program and debug in-system, no external programmer required
- 128Mbit OSPI Flash for ZYNQ boot image and user data
- HDMI transmit (configurable as receive)
- 10/100 Ethernet for network communication
- 1x USB Host port
- SD card slot for system boot and filesystem
- 1x USB-UART for ZYNQ-to-PC communication
- 2x 40-pin 2.54mm expansion headers — 72 I/Os at 3.3V
Specifications
| Item | Specification |
|---|---|
| SoC | Xilinx Zynq-7020 |
| DDR3 | 4Gbit, 1066Mbps |
| USB-JTAG | Onboard |
| OSPI Flash | 128Mbit |
| HDMI | 1x TX (configurable as RX) |
| Ethernet | 1x 10/100 |
| USB Host | 1x |
| SD Card | 1x |
| USB-UART | 1x |
| Clock | PS 33.3333MHz, PL 50MHz |
| Buttons | PS x1, PL x2 |
| LEDs | PS x1, PL x2 |
| Expansion | 2x 40-pin 2.54mm, 72 I/Os @ 3.3V |
Pricing available on request — use the “Request a Quote” button for B2B inquiries.
