Key Features
- Xilinx Zynq-7020 SoC (ARM Cortex-A9 + FPGA fabric)
- Onboard USB-JTAG — program and debug in-system, no external programmer required
- 256Mbit QSPI Flash for ZYNQ boot image and user data
- Gigabit Ethernet (10/100/1000 auto-sensing)
- USB Host and USB Slave ports
- SD card slot for system boot images and filesystem
- HDMI output (configurable as input), 1080P video
- 32Kb I2C EEPROM (24C32)
- 6 user buttons (2 PS + 4 PL) + 1 system reset
- 6 user LEDs (2 PS + 4 PL) + 2 system LEDs (power, download)
- 8-layer gold-plated PCB with dedicated power and ground planes, 125x90mm
Specifications
| Item | Specification |
|---|---|
| SoC | Xilinx Zynq-7020 |
| USB-JTAG | Onboard, in-system download and simulation |
| QSPI Flash | 256Mbit |
| Ethernet | 1x 10/100/1000 auto-sensing |
| USB Host | 1x |
| USB Slave | 1x |
| SD Card | 1x |
| USB-UART | 1x |
| HDMI | 1x output (configurable as input), 1080P |
| EEPROM | 32Kb I2C (24C32) |
| Clock | PS 33.333MHz, PL 50MHz |
| Buttons | 1 system reset + 6 user (2 PS, 4 PL) |
| LEDs | 2 system (power, download) + 6 user (2 PS, 4 PL) |
| Power | DC 5V/2A |
| PCB | 8-layer gold-plated, dedicated power/ground planes, 125x90mm |
Pricing available on request — use the “Request a Quote” button for B2B inquiries.
