Key Features
- AMD Xilinx Zynq UltraScale+ RFSoC XCZU47DR-2FFVE1156E — integrated direct RF sampling
- 8x 14-bit RF-ADC (up to 5GSPS) + 8x 14-bit RF-DAC (up to 9.85GSPS)
- NVIDIA Jetson AGX Orin / AGX Thor module (optional) — 241 to 2070 TOPS AI compute
- PCIe Gen3 x8 high-speed interconnect between RFSoC and Jetson (80Gbps)
- 930K logic cells, 425K LUTs, 4272 DSP Slices
- Quad-core ARM Cortex-A53 + dual-core Cortex-R5
- 6GB DDR4 (PS 4GB + PL 2GB), 32GB eMMC Flash, 256MB QSPI Flash
- 8x GTY transceivers at 28.21Gb/s
- Industrial temperature range: -40°C to 85°C
Specifications — ACW47 Core Module
| Item | Specification |
|---|---|
| FPGA | XCZU47DR-2FFVE1156E (Zynq UltraScale+ RFSoC) |
| ARM Processor | Quad Cortex-A53 + dual Cortex-R5 |
| Logic Cells | 930K |
| LUTs | 425K |
| DSP Slices | 4,272 |
| GTY Transceivers | 8x @ 28.21Gb/s |
| RF-ADC | 8x 14-bit, up to 5GSPS |
| RF-DAC | 8x 14-bit, up to 9.85GSPS |
| DDR4 | 6GB (PS 4GB + PL 2GB) |
| QSPI Flash | 256MB |
| eMMC Flash | 32GB |
| Operating Temp | Industrial, -40°C to 85°C |
NVIDIA Jetson Module Options
| Spec | Jetson Thor T5000 | AGX Orin 64GB | AGX Orin 32GB |
|---|---|---|---|
| AI Performance | 2070 FP4 TFLOPS | 275 TOPS | 241 TOPS |
| GPU Architecture | NVIDIA Blackwell | NVIDIA Ampere | NVIDIA Ampere |
| GPU Cores | 2560 | 2048 | 1792 |
| Tensor Cores | 96 (5th gen) | 64 | 56 |
| CPU | 14-core Arm Neoverse-V3AE | 12-core Cortex-A78AE | 8-core Cortex-A78AE |
| Memory | 128GB LPDDR5X | 64GB LPDDR5 | 32GB LPDDR5 |
| Bandwidth | 276 GB/s | 204.8 GB/s | 204.8 GB/s |
| Power Range | 40W ~ 130W | 15W ~ 60W | 15W ~ 40W |
RFSoC-side Interfaces
- 8x 14-bit RF-ADC input (max 5GSPS)
- 8x 14-bit RF-DAC output (max 9.85GSPS)
- 1x Gigabit Ethernet
- 2x USB 3.0 Type-C (Host/Slave)
- 1x Micro SD card slot
- 1x UART debug (mini USB)
- 1x 10-pin 2.54mm JTAG
- 4x user LEDs, 4x buttons
Jetson-side Interfaces
- 1x 10G Ethernet (for Orin AGX) / 1x 5G Ethernet (for Thor)
- 1x DisplayPort (4K@30Hz or 1080P@60Hz)
- 1x M.2 Key M (NVMe SSD)
- 1x M.2 Key E (Wi-Fi/Bluetooth)
- 2x USB 3.2 Type-C (Host/OTG/Slave)
- 1x UART (2.54mm 3-pin)
- 1x 40-pin expansion header
- 1x MicroSD slot (Orin only)
- 2x buttons (reset + recovery), 1x user LED
Power & Dimensions
- Input power: +12V
- Carrier board: 260mm x 215mm
- Core module: 90mm x 80.5mm
Shipping List
- FPGA development board x1
- Cooling fan x1
- Type-C cable x1
- SMA cable x2
- SD card x1
- Card reader x1
- USB downloader x1
- 12V power supply x1
Applications
Satellite communications, 5G base stations & wireless, radar systems, test & measurement.
Pricing available on request — use the “Request a Quote” button for B2B inquiries.
