Key Features
- 4x SFP+ optical interfaces — up to 10.3125Gbps
- HDMI output at 720P@60Hz
- PCIe 2.0 (x4 for XME0735, x8 for XME7100)
- M.2 slot (XME7100 only)
- Dual Gigabit Ethernet (1x PS, 1x PL)
- 4x USB 2.0 host ports for mouse, keyboard, etc.
- 1x USB-UART for ZYNQ-to-PC serial communication
- 10-pin 2.54mm standard JTAG debug header
- 1 power LED + 4 PL user LEDs
- Configurable clock chip with 4 output groups
Specifications
| Item | Specification |
|---|---|
| SFP+ | 4x, up to 10.3125Gbps |
| HDMI | 1x output, 720P@60Hz |
| PCIe 2.0 | x4 (XME0735) / x8 (XME7100) |
| M.2 | Not supported (XME0735) / Supported (XME7100) |
| Ethernet | 2x GbE (1x PS, 1x PL) |
| USB 2.0 | 4x host ports |
| USB-UART | 1x |
| JTAG | 10-pin 2.54mm standard |
| LEDs | 1 power, 4 PL user |
| Clock | Configurable, 4 output groups |
Pricing available on request — use the “Request a Quote” button for B2B inquiries.
